OHR-DVBT2CI-00 4 channel DVB-T2 (COFDM) receiver module
$1,047.14 Each Add to cart

Wellav - OHR-DVBT2CI-00 4 channel DVB-T2 (COFDM) receiver module

$1,047.14 Each

4-channel DVB-T/T2 (COFDM)receiver module (one F connector, Support internal signal passthrough,) with two CAM slots.

fits the OnmiHub-16 chassis

Ships in 3 to 4 Weeks
Safe Checkout


  • Input 4 channels via 1 RF female connector
  • CI 2 x PCMCIA CI slots
  • CAM Descrambled channel quantity depends on CAM capability, 2 CAMs could be different
  • Frequency Range 47~862MHz
  • Bandwidth 6/7/8MHz
  • Constellation DVB-T: QPSK/16QAM/64QAM / DVB-T2: QPSK/16QAM/64QAM/256QAM
  • Guard Interval DVB-T: 1/4, 1/8, 1/16, 1/32 / DVB-T2: 1/4, 1/8, 1/16, 1/32, 1/128 /19/256, 19/128
  • FFT Size DVB-T: 2K, 8K / DVB-T2: 1K, 2K, 4K, 8K, 16K, 32K
  • Signal Level -80~-20dBm
  • CA System Supports mainstream CAS
  • Power Consumption Max. 8W




Leading Global Provider of Professional Video Delivery Solutions Wellav Technologies is committed to developing and manufacturing the best value video processing and monitoring equipment and solutions to help pay-tv operators address real business challenges in video distribution. Through innovation and cutting-edge technologies, Wellav continues to provide a full range of digital headend equipment, STBs and value-added solutions to meet the growing demands of pay-tv services such as multi-screen, IPTV/OTT and VOD. The company’s global service and support organizations are providing system integration and technical expertise to support CATV, FTTH, IPTV/OTT, Satellite/Terrestrial, Broadband/ADSL operators to deliver high-quality video programs to millions of viewers around the world.

Additional information

Weight 1.5 lbs
Dimensions 12.5 × 7 × 3 in
