FiberLinkB Plus L Band Fiber Optic Link
Call for Price Add to cart

RF Design - FiberLinkB Plus L Band Fiber Optic Link

Call for Price

The broadband FiberLinkBplus RF-over-Fiber system for non-redundant optical transmission of RF signals is available in sizes of 1RU/19″ & 3RU/19″ rack mount design. It is perfectly suited for flexible and high quality optical transmission of up to 16 RF signals (broadband 50 – 2500MHz) over a distance of up to 20km.

The 1RU/19″ chassis variants hold up to 4 optical TX/RX modules while the 3RU/19″ chassis can be populated with up to 16 TX/RX modules.

All available chassis are designed to allow mixed population with TX/RX modules within the same chassis, while the chassis are equipped with corresponding RF ports (50Ohm or 75Ohm) which are used either as input or output port as per the individual configuration.

Additionally, this non-redundant RF-over-Fiber system comes with beneficial features such as Laser/Link monitoring, status LED´s at any TX/RX module, variable gain control, RF power monitoring, hot swappable TX/RX modules and 1:1 redundant dual power-supply. Configuration and monitoring is possible via the front-panel LC-Display or 5,7″ touchscreen while remote configuration is available via its Ethernet-Interface (WebGUI, SNMP).

This professional RF-over-Fiber system stands for perfect RF performance as well as stable signal distribution and is perfectly suited for Teleports, Satellite Earth Stations, Broadcasting and Cable/IPTV operations.

Safe Checkout

Description

  • Versatile non redundant RF-over-Fiber system
  • Broadband frequency range 50 – 3000MHz
  • 1RU/19″ chassis for max. 4 TX/RX modules
  • 3RU/19″ chassis for max. 16 TX/RX modules
  • Hot swappable TX/RX modules
  • Support of mixed TX/RX population
  • Variable gain-control at each TX/RX module
  • RF power monitoring at each TX/RX module
  • Switchable LNB-supply @ each TX module (Option)
  • Status LED´s for each TX/RX module
  • Easy local & remote configuration & monitoring
  • Laser, link, PSU & access status monitoring
  • Excellent quality and superior RF performance
  • 1:1 redundant dual power-supply

Brand

RF Design

RF Design's products are developed with highest quality levels focusing most excellent technical performance. Additionally RF Design is strong in designing customized solutions fullfilling exactly your requirements. Permanent research guarantees high quality and best performance. This includes the selection process of components and the ongoing design optimization of mechanical parts. Steady prototyping and intensive test periodes are ensuring best results in terms of functionality , specifications and performance.
