PSA-2500C Portable Spectrum Analyzer 5-2500 MHz
$5,035.00 Each Add to cart

Avcom - PSA-2500C Portable Spectrum Analyzer 5-2500 MHz

$5,035.00 Each

Compact Design-Improved Performance and Specifications from AVCOM
Whether you are doing a satellite installation, troubleshooting a CATV or broadcast system, setting up a remote telemetry system, trying to locate a threatening jamming device, or locating eavesdropping devices, the AVCOM PSA has something to offer. Designed for the teleport, oil and gas, maritime, broadcast, military, TCSM, and wireless community, the PSA is compact, portable, lightweight, and budget friendly for quick and precise signal investigations. Being intuitive and easy to operate and providing many functions to facilitate quick and easy measurements, the PSA is an indispensable tool for engineers and technicians who conduct field measurements anywhere in the 5MHz to 2.5GHz range. For technicians demanding a greater range, AVCOM’s external down converters may be used to extend the range up to 6.5GHz.

The color LCD display provides the user with an accurate and detailed picture of the spectrum being investigated, even when operating under challenging bright sunlight or other difficult lighting conditions. The field replaceable Li-Ion battery uses an internal charger and a multi segment battery status indicator is provided. The PSA comes equipped with 13V/18V/22kHz LNB power to directly power the satellite LNB, and programmable LO Offset selection provides no-math direct frequency readouts of low side or high side LNB’s. Up to ten user-defined presets allow for executing quick repetitive testing parameters. Screenshots may be saved on the PSA and can be recalled on-screen for comparing signal footprints or can be downloaded to a PC using AVCOM’s free software for documentation. The number of applications and features of the PSA are endless so contact us today!

Versatile Remote Control Software
The PSA can be monitored and controlled both locally from the front panel and remotely using the Avcom Remote Control Software via serial port or Ethernet. The Remote Control Software has an intuitive user interface that is easy to use with no special training required. It allows remote monitoring and control from your network or over the internet. Features include screenshot capture recording, SMNP for alarm/monitoring, markers, cross-polling and Automated Data Acquisition (DAQ) with tolerance comparison and integrated email alerts, to name a few. Up to twelve windows can be displayed at one time. The GUI is capable of saving and recalling an unlimited number of screenshots and integrates with the PSA to upload or download saved waveforms from the analyzer’s internal user memory locations. The Remote Control Software is available for Windows, Mac, and Linux.

Ships in 1 to 2 weeks
Safe Checkout

Description

  • Small Compact Design
  • Battery Powered for Remote Field Use
  • 13/18 Volt LNB Power & 22 KHz
  • 4 Resolution Bandwidth Selections including 10 KHz
  • Ethernet & Serial Communications
  • Ability to Monitor the 10MHz Reference Signal
  • User Friendly and Intuitive GUI

Brand

Avcom

High Quality, Low Cost Spectrum Analyzers AVCOM of Virginia has over 25 years of experience in designing and manufacturing high quality, low cost spectrum analyzers. Founded in 1976, AVCOM initially targeted the satellite receiver industry with its PSR-3 Satellite Receiver. This product differentiated itself from the competition with its unique “Scan-Tune” functionality which allowed the receiver to be tuned back and forth across all transponders once every 3 seconds. In 1985, AVCOM developed a unique low-cost spectrum analyzer modeled after their high-end competitors, but without the extreme performance and much more affordable. The PSA-35 Spectrum Analyzer was introduced to the market at the 1986 Satellite Show in Las Vegas. Since then, AVCOM has continued to expand their product portfolio with remote, rack-mounted and portable spectrum analyzer solutions. It’s this resourcefulness that has allowed AVCOM to remain a market leader in providing affordable spectrum analyzer solutions to customers and markets worldwide.

Additional information

Weight 7 lbs
Dimensions 22 × 24 × 14 in
